fix: establish lighting phase zero baselines

[MichaelFisher1997]

Summary

• align the four-cascade shadow UBO across CPU, GLSL, and checked-in SPIR-V with a reflection-based ABI gate
• transition every shadow array layer with complete early/late depth dependencies and use the physically allocated resolution for fitting and sampling
• recreate shadow resources transactionally at frame boundaries when quality changes
• add deterministic lighting fixtures, settled capture orchestration, canonical debug channels, and UNORM screenshot sRGB encoding/metadata
• document the repeatable capture matrix and commit the 60-second high-preset baseline

Verification

• nix develop --command zig build test
• nix develop --command zig build -Dskip-present
• pre-push formatting and full test hooks
• deterministic shadow-world startup: 49/49 chunks renderable, generation/mesh/upload queues empty
• 60-second high benchmark generated docs/benchmarks/lighting-phase0-high.json; it records existing draw-call and GPU-memory SLO breaches

Known Existing Failure

• nix develop --command zig build test-robustness does not compile on the repository Zig 0.16 toolchain because src/integration_test_robustness.zig still switches on the removed .Exited process term tag

Closes #900

[github-actions]

kcov coverage

Line coverage ran for this PR and uploaded a non-blocking report artifact named kcov-report. Codecov upload is configured as non-blocking while the project captures a stable baseline.

[github-actions]

📋 Summary

PR #905 closes #900 and establishes the phase-zero lighting baseline: it aligns the four-cascade shadow UBO across CPU, GLSL, and checked-in SPIR-V via a compile-time ABI gate plus a SPIR-V reflection script; adds transactional shadow-map recreation at frame boundaries; switches cascade fitting/sampling to the backend-allocated physical resolution; extends the deterministic zigcraft:shadow-test world with canonical fixtures; adds screenshot settle logic and UNORM-to-sRGB PNG encoding; and commits the 60-second high-preset baseline.

The stated issue requirements are satisfied: deterministic fixtures, a repeatable capture matrix, and documented baselines are present and verified.

nix develop --command zig build test passes, including the new scripts/check_shadow_abi.sh gate. The PR body correctly notes that the pre-existing test-robustness compile failure is not addressed here.

📌 Review Metadata

• Reviewed Commit SHA: 08787e0a445c564d5a15c4d112a5cd12545b0bf6
• Reviewed PR: fix: establish lighting phase zero baselines #905
• Linked Issue: [Lighting Overhaul][Phase 0] Establish visual baselines and repair pipeline contracts #900
• Implementation Status: The PR implements the issue scope described above.

🔴 Critical Issues (Must Fix - Blocks Merge)

None identified.

⚠️ High Priority Issues (Should Fix)

None identified.

💡 Medium Priority Issues (Nice to Fix)

None identified.

ℹ️ Low Priority Suggestions (Optional)

[LOW] assets/shaders/vulkan/terrain.frag:117 and assets/shaders/vulkan/sky.frag:38 - Outdated ShadowUniforms comment
Confidence: High
Description: Both GLSL blocks comment shadow_params as // x = light_size (PCSS), y/z/w reserved, but the CPU now writes y = 1.0 / shadow_resolution and terrain.frag reads shadows.shadow_params.y for inverse resolution and texel-size margins.
Impact: ABI comment drift; future maintainers may assume the field is free and overwrite it.
Suggested Fix: Update the comment to // x = light_size (PCSS), y = 1 / shadow resolution, z/w reserved in both shaders.

[LOW] modules/engine-graphics/src/vulkan/rhi_state_control.zig:188 - setShadowResolution is not synchronized with ctx.mutex
Confidence: Low
Description: setShadowResolution writes pending_shadow_resolution while beginFrame reads it under ctx.mutex. This is consistent with existing options setters like setMSAA, but it remains a latent data race if the settings/UI path ever runs off the render thread.
Impact: Rare stale or torn resolution change on weakly-ordered memory.
Suggested Fix: Either document the render-thread-only contract in the function or acquire ctx.mutex before writing, matching the convention used by beginFrame.

[LOW] scripts/check_shadow_abi.sh:20 - Brittle ABI verification via exact substring matching
Confidence: Low
Description: The script asserts exact glslang reflection text such as "ShadowUniforms: offset -1, type ffffffff, size 304". A future glslang version that changes formatting will fail the gate even when the ABI is correct.
Impact: Fragile CI that can produce false negatives on toolchain updates.
Suggested Fix: Add a small normalizer or switch to a structured reflection tool (e.g., spirv-reflect) if the toolchain allows.

📊 SOLID Principles Score

Principle	Score	Notes
Single Responsibility	8	Each module has a clear role; shadow recreation is isolated in rhi_frame_orchestration.
Open/Closed	7	Compile-time ABI guards make the shadow layout hard to break; new debug channels still touch enum and shader.
Liskov Substitution	8	VTable default for getResolution keeps mock implementations compiling.
Interface Segregation	7	setShadowResolution appears in both IRenderSettings and IRenderQualityOptions; duplication is minor but could be consolidated.
Dependency Inversion	8	RHI interface abstracts Vulkan; shadow code uses IShadowContext.
Average	7.6

🎯 Final Assessment

Overall Confidence Score: 88%

Confidence Breakdown:

• Code Quality: 85%
• Completeness: 90%
• Risk Level: 80%
• Test Coverage: 85%

Merge Readiness:

• All critical issues resolved
• SOLID average score >= 6.0
• Overall confidence >= 60%
• No security concerns
• Tests present and passing

Verdict:

MERGE

The PR lands the phase-zero baseline cleanly with passing tests and no safety blockers; only minor documentation and low-risk polish items remain.

{
  "reviewed_sha": "08787e0a445c564d5a15c4d112a5cd12545b0bf6",
  "critical_issues": 0,
  "high_priority_issues": 0,
  "medium_priority_issues": 0,
  "overall_confidence_score": 88,
  "recommendation": "MERGE"
}

opencode session  |  github run
