HTML2PDF API Logo

Fast HTML to PDF, Screenshots, and Video API

A lightweight, high-performance rendering API built on Puppeteer. This is the open-source version of the software powering html2pdfapi.com. The SaaS version includes additional features out of the box:

  • Async support with a job queue for background processing
  • Webhook notifications when jobs complete
  • Direct S3 upload to your own bucket

Features

  • 📸 PNG, JPEG, WebP, GIF, AVIF screenshots from any URL or HTML
  • 📄 PDF generation with full page layout control
  • 🎬 MP4 video recording with smooth scroll animation
  • 🌐 Full HTML capture with all resources embedded inline
  • ⚡ Browser pool with configurable recycling and warmup
  • 🔧 Structured JSON logging (Pino)
  • 🐳 Docker-ready with CI pipeline

Getting Started

Requirements

  • Node.js 24+
  • FFmpeg (for video recording)

Local Development

npm install
npm run dev

The server starts on http://localhost:3000. API docs are available at /docs.

For video support on macOS (Homebrew):

FFMPEG_PATH=/opt/homebrew/bin/ffmpeg npm run dev

Docker

Pull from the GitHub Container Registry:

docker pull ghcr.io/carbogninalberto/fast-html-to-pdf-api:latest
docker run -p 3000:3000 ghcr.io/carbogninalberto/fast-html-to-pdf-api:latest

Or build locally:

docker build . -t bakney/fastrender
docker run -p 3000:3000 bakney/fastrender

For ARM-based machines (Apple Silicon):

docker build --platform linux/amd64 . -t render
docker run --platform linux/amd64 -p 3000:3000 render

API Usage

Endpoints

Endpoint Method Description
/render POST Render URL or HTML to PDF/Image/Video/HTML
/render?config=... GET Same as above, with JSON config as query param
/health GET Health check with browser pool stats
/ping GET Simple connectivity check (returns "pong")
/docs GET Swagger API documentation

Request Parameters

Parameter Type Required Description
url string One of url or html URL to render
html string One of url or html Raw HTML content to render
type string Yes image, pdf, video, or html
headers object No Custom HTTP headers to send with the request
device object No Viewport settings (width, height, scale, userAgent, locale, timezone)
render object No Render options (waitTime, fullPage, scroll, block)
image object No Image settings (type, quality, compression, crop, resize, rotation)
pdf object No PDF settings (format, width, height, margins, orientation, header/footer)
video object No Video settings (fps, duration, codec, bitrate, crf, preset)

Device Options

Configure the browser viewport and device emulation.

Parameter Type Default Description
width number 1920 Viewport width in pixels
height number 1080 Viewport height in pixels
scale number 1 Device scale factor (DPR)
userAgent string Chrome default Custom user agent string
locale string en-US Browser locale (e.g., fr-FR, de-DE)
timezone string UTC Timezone (e.g., Europe/London, America/New_York)
javascriptEnabled boolean true Enable/disable JavaScript execution

Render Options

Control page loading and rendering behavior.

Parameter Type Default Description
waitTime number 0 Additional wait time after page load (ms)
timeout number 30000 Page load timeout (ms)
fullPage boolean false Capture full scrollable page (images only)
triggerLazyAnimations boolean false Scroll page to trigger lazy-loaded content
waitUntil string networkidle0 Wait condition: load, domcontentloaded, networkidle0, networkidle2
scroll.position number 0 Scroll to position before capture (px)
scroll.animate boolean false Enable scroll animation (video)
scroll.duration number 5000 Scroll animation duration (ms)
scroll.animation string smooth Scroll animation style
block.cookies boolean false Block cookie consent banners
block.ads boolean false Block advertisements
block.trackers boolean false Block tracking scripts
block.banners boolean false Block promotional banners

PDF Options

Full control over PDF generation. Supports custom page dimensions with units.

Parameter Type Default Description
format string A4 Paper format: A0-A6, Letter, Legal, Tabloid, Ledger
width string - Custom width with units (e.g., 210mm, 8.5in, 600px)
height string - Custom height with units (e.g., 297mm, 11in, 800px)
landscape boolean false Landscape orientation
scale number 1 Scale of the webpage rendering (0.1 to 2)
printBackground boolean true Print background graphics
displayHeaderFooter boolean false Display header and footer
headerTemplate string "" HTML template for header
footerTemplate string "" HTML template for footer
pageRanges string "" Page ranges to print (e.g., 1-5, 1,3,5)
preferCSSPageSize boolean false Use CSS-defined page size
omitBackground boolean false Hide default white background
margin.top string 0px Top margin with units
margin.right string 0px Right margin with units
margin.bottom string 0px Bottom margin with units
margin.left string 0px Left margin with units

Supported units: px, in, cm, mm

Note: When using custom width or height, the format option is automatically ignored.

Image Options

Configure screenshot output format and post-processing.

Parameter Type Default Description
type string png Output format: png, jpeg, webp, gif, avif
quality number 100 Image quality (0-100, for jpeg/webp)
compression number 0 PNG compression level (0-9, 0=fastest)
smooth boolean true Enable adaptive filtering for PNG
resize number 1 Resize factor (0.1 to 3)
rotate number 0 Rotation angle (0-360 degrees)
roundedBorders number/boolean false Border radius in pixels
padding number 0 Padding in pixels
crop.left number - Crop area left offset
crop.top number - Crop area top offset
crop.width number - Crop area width
crop.height number - Crop area height

Video Options

Configure MP4 video recording with scroll animation.

Parameter Type Default Description
fps number 60 Frames per second
followNewTab boolean true Follow navigation to new tabs
videoCrf number 23 Constant Rate Factor (0-51, lower=better quality)
videoCodec string libx264 Video codec
videoPreset string ultrafast Encoding preset: ultrafast, superfast, veryfast, faster, fast, medium, slow, slower, veryslow
videoBitrate number 3000 Bitrate in kbps (500-10000)
recordDurationLimit number 30 Maximum recording duration in seconds
videoFrame.width number 1920 Video frame width
videoFrame.height number 1080 Video frame height

Examples

Screenshot from URL:

curl -X POST http://localhost:3000/render \
  -H "Content-Type: application/json" \
  -d '{"url": "https://example.com", "type": "image"}' \
  --output screenshot.png

PDF from HTML:

curl -X POST http://localhost:3000/render \
  -H "Content-Type: application/json" \
  -d '{
    "html": "<!DOCTYPE html><html><body><h1>Hello</h1></body></html>",
    "type": "pdf",
    "pdf": {"format": "A4", "margin": {"top": "20px", "bottom": "20px"}}
  }' \
  --output output.pdf

PDF with custom dimensions (mm):

curl -X POST http://localhost:3000/render \
  -H "Content-Type: application/json" \
  -d '{
    "url": "https://example.com",
    "type": "pdf",
    "pdf": {
      "width": "210mm",
      "height": "400mm",
      "margin": {"top": "10mm", "bottom": "10mm", "left": "10mm", "right": "10mm"}
    }
  }' \
  --output custom-size.pdf

PDF with custom dimensions (inches - US Letter):

curl -X POST http://localhost:3000/render \
  -H "Content-Type: application/json" \
  -d '{
    "url": "https://example.com",
    "type": "pdf",
    "pdf": {
      "width": "8.5in",
      "height": "11in",
      "margin": {"top": "0.5in", "bottom": "0.5in", "left": "0.5in", "right": "0.5in"}
    }
  }' \
  --output letter.pdf

Receipt/ticket PDF (narrow format):

curl -X POST http://localhost:3000/render \
  -H "Content-Type: application/json" \
  -d '{
    "html": "<html><body style=\"font-family:monospace\"><h2>RECEIPT</h2><hr><p>Item 1...$10.00</p><p>Total: $10.00</p></body></html>",
    "type": "pdf",
    "pdf": {"width": "80mm", "height": "200mm", "margin": {"top": "5mm", "bottom": "5mm", "left": "5mm", "right": "5mm"}}
  }' \
  --output receipt.pdf

PDF with header and footer:

curl -X POST http://localhost:3000/render \
  -H "Content-Type: application/json" \
  -d '{
    "url": "https://example.com",
    "type": "pdf",
    "pdf": {
      "format": "A4",
      "displayHeaderFooter": true,
      "headerTemplate": "<div style=\"font-size:10px;text-align:center;width:100%\">Company Name</div>",
      "footerTemplate": "<div style=\"font-size:10px;text-align:center;width:100%\">Page <span class=\"pageNumber\"></span> of <span class=\"totalPages\"></span></div>",
      "margin": {"top": "20mm", "bottom": "20mm", "left": "10mm", "right": "10mm"}
    }
  }' \
  --output with-header-footer.pdf

WebP image with custom quality:

curl -X POST http://localhost:3000/render \
  -H "Content-Type: application/json" \
  -d '{"url": "https://example.com", "type": "image", "image": {"type": "webp", "quality": 80}}' \
  --output output.webp

Video with scroll animation:

curl -X POST http://localhost:3000/render \
  -H "Content-Type: application/json" \
  -d '{
    "url": "https://example.com",
    "type": "video",
    "video": {"fps": 24},
    "render": {"scroll": {"animate": true, "duration": 3000}}
  }' \
  --output output.mp4

Full HTML capture (resources embedded as data URIs):

curl -X POST http://localhost:3000/render \
  -H "Content-Type: application/json" \
  -d '{"url": "https://example.com", "type": "html"}' \
  --output page.html

Mobile viewport screenshot:

curl -X POST http://localhost:3000/render \
  -H "Content-Type: application/json" \
  -d '{
    "url": "https://example.com",
    "type": "image",
    "device": {
      "width": 375,
      "height": 812,
      "scale": 2,
      "userAgent": "Mozilla/5.0 (iPhone; CPU iPhone OS 15_0 like Mac OS X) AppleWebKit/605.1.15"
    }
  }' \
  --output mobile.png

Full page screenshot with lazy loading:

curl -X POST http://localhost:3000/render \
  -H "Content-Type: application/json" \
  -d '{
    "url": "https://example.com",
    "type": "image",
    "render": {
      "fullPage": true,
      "triggerLazyAnimations": true,
      "waitTime": 1000
    }
  }' \
  --output fullpage.png

Cropped and resized screenshot:

curl -X POST http://localhost:3000/render \
  -H "Content-Type: application/json" \
  -d '{
    "url": "https://example.com",
    "type": "image",
    "image": {
      "type": "png",
      "crop": {"left": 0, "top": 0, "width": 800, "height": 600},
      "resize": 0.5
    }
  }' \
  --output cropped.png

Screenshot with custom headers and locale:

curl -X POST http://localhost:3000/render \
  -H "Content-Type: application/json" \
  -d '{
    "url": "https://example.com",
    "type": "image",
    "headers": {"Authorization": "Bearer token123"},
    "device": {"locale": "fr-FR", "timezone": "Europe/Paris"}
  }' \
  --output french.png

GET request with config parameter:

curl "http://localhost:3000/render?config=%7B%22url%22%3A%22https%3A%2F%2Fexample.com%22%2C%22type%22%3A%22image%22%7D" \
  --output screenshot.png

Demo Script

A comprehensive test script is included to demonstrate PDF custom dimensions:

./pdf.demo.examples.sh

This generates 26 PDFs with various sizes (A3, A5, Letter, Legal, custom dimensions in mm/in/cm/px, receipts, posters, etc.) in the pdf-demo-examples/ directory.

Configuration

All settings are driven by environment variables with sensible defaults.

Server

Variable Default Description
SERVER_PORT 3000 HTTP server port
BODY_LIMIT_BYTES 52428800 Max request body size (50 MB)
SHUTDOWN_TIMEOUT_MS 30000 Graceful shutdown timeout
LOG_LEVEL info Log level (trace, debug, info, warn, error, fatal)

Browser Pool

Variable Default Description
POOL_MIN 2 Minimum browser instances
POOL_MAX 10 Maximum browser instances
POOL_ACQUIRE_TIMEOUT_MS 30000 Max wait to acquire a browser
POOL_IDLE_TIMEOUT_MS 30000 Idle time before eviction
BROWSER_MAX_AGE_MS 600000 Max browser lifetime (10 min)
BROWSER_MAX_REQUESTS 100 Max requests per browser before recycling
BROWSER_MAX_MEMORY_MB 500 Memory limit per browser

Video

Variable Default Description
FFMPEG_PATH /usr/bin/ffmpeg Path to FFmpeg binary
VIDEO_MAX_SCROLL_DURATION_MS 20000 Max scroll animation duration

Viewport

Variable Default Description
DEFAULT_VIEWPORT_WIDTH 1920 Default viewport width
DEFAULT_VIEWPORT_HEIGHT 1080 Default viewport height

Testing

Unit Tests

npm test

With coverage report (97% line coverage required):

npm run coverage

End-to-End Tests

Requires a running server on port 3000:

# Terminal 1: start the server
FFMPEG_PATH=/opt/homebrew/bin/ffmpeg node app/server.js

# Terminal 2: run E2E tests
npm run test:e2e

E2E tests validate output format correctness using magic bytes (PNG, WebP, PDF headers, MP4 ftyp box, HTML structure).

CI

The GitHub Actions workflow runs on every push:

  1. Unit tests with 97% coverage gate
  2. Docker build
  3. E2E tests against the running container

Health Check

GET /health returns pool status and memory usage:

{
  "status": "healthy",
  "timestamp": "2026-01-22T12:00:00.000Z",
  "browserPool": {
    "available": 2,
    "borrowed": 1,
    "pending": 0,
    "min": 2,
    "max": 10
  },
  "uptime": 3600,
  "memory": {
    "used": "256 MB",
    "total": "512 MB"
  }
}

Returns 200 when healthy, 503 when degraded (no browsers available).

License

For usage in commercial services, please refer to the license.txt file in this repository.

Note: License is not enforced, but we are a small team, and any support to further develop this product would be greatly appreciated! 🙏

About

A high-performance API for converting HTML to PDF, capturing screenshots, and generating videos. Built to handle demanding workloads at scale.

html2pdfapi.com

Resources

Readme

License

View license
Activity

Stars

14 stars

Watchers

2 watching

Forks

0 forks
Report repository

Releases 9

v1.2.1 Latest
Feb 4, 2026
+ 8 releases

Packages





Contributors

Languages
