the capybara robot is an open source and open hardware differential drive robot. Powered by a dspic33fj128mc802 it provides an highly customizable firmware, a full extensible serial commands stack and an high speed PID control loop up to 1khz for each motor.
The firmware source code is available https://github.com/mauriliodc/capybara
All nodes expose a lot of standard-ros command line arguments to let the user customize some aspects. The source code is ridiculously simple to be modified in two minutes.
-
capybarauno_node
the main node, it will subscribe to a capybarauno::ticks topic and communicate with the robot base requested a specific velocity (requested as left/right ticks) and publishes the robot ticks
-
capybarauno_joy2ticks
the node will subscribe to joy topic and convert the data from two axii into ticks
-
capybarauno_twist2ticks
the node will subscribe to a cmv_vel topic and convert the data into ticks
-
capybarauno_ticks2odo
the node subscribes to the published ticks from the main node and computes/publises the odometry
